Description
This app supports DWG and DXF files. CadPoint designed for mobile devices and contains tools, that increase your productivity on touch screens. We trying to make designing fast, like on the desktop, and mobile - to work in the field.
The application allows you to work with the LiDAR sensor, built-in into the iPad Pro 11 (2nd generation) or iPad pro 12.9 (4th generation). You can scan surroundings and analyse it into CadPoint: measure various dimensions such as width, height, length, area. Also you will be able to perform simple editing with your scans.
The scanner can classify the following objects: wall, ceiling, floor, door, window, table or seat. Classified objects are saved in separate layers into DWG file.
App contains 2D drawing tools, in each step you could edit new entities with precision. Auto entity analyzes the drawing path and can recognize a segment as:
* Polyline
* Arc
* Circle
Also, you can use tools, that draw certain type of entity:
* Polyline
* Circle
* Multiline
* Text, MText
* Table entities
* Hatch with patterns
* Cloud, Marker for markups
Edit your drawings with snap and grip points just like on computer. Also you can set length/angle values to entities - this tools uses a parametric engine, specially designed for touch screens.
Edit your drawing with a set of frequently used CAD tools:
* Move, Copy, Scale, Rotate
* Undo, Redo
* Offset, Mirror
* Join, Explode
* Send-To-Back, Bring-To-Front
* Entity Filter Tool
Measuring tools contains:
* Distance measurement (supports 2D and 3D)
* Area measurement
* Ortho measurement tool
* Position tool (2D and 3D modes)
You could connect your rangefinder to this App. It supports:
* Bosch GLM50C
* Bosch GLM100C
* Bosch GLM120C
* Leica DISTO D110, D1, D2
* Leica DISTO D510, D810, S910
* Leica DISTO X3, D8
* Condtrol Vector
Also you could use layers, layouts, views, color management in this App.
Plot drawing to pdf/jpeg images, or directly to AirPrint device.
You can work with drawings from any source: iCloud, Dropbox, Google Drive, Box, email, or use internal storage. Share drawings by email, Files or other App.
What's New in Version 1.7
This App using LiDAR sensor to scan environment. Scan available in iPad Pro 11 (2nd generation) or iPad Pro 12.9 (4th generation)
This version contains scanner improvements:
- Add simple entities to AR scene: Point, Polyline, Polygon
- Measure length and area in the environment
- Save scene with created entities and measurements in DWG file
The measurements accuracy made with LiDAR sensor depends on the accuracy of the accelerometer and gyroscope. Errors accumulate while iPad camera moves. According to our observations, it is about 1% of the measured line length.
Also we added some CAD changes available to all devices:
- dynamic blocks support
- text size tool
- iOS 14 supports
Thanks for your feedback! We take it into account in application development.
